BDC Carbine Reticle: Developed specifically for the trajectory of the .223 Rem/5.56 NATO round with 55-grain polymer tip bullet, the new BDC Carbine reticle provides a 200 yard crosshair with “hash marks” at 400 yards and 600 yards.
100-yard Parallax Setting: Eliminates parallax for precise shooting.
Precise, 1/2″ Hand-turn Tactical-Style Turrets: Positive click reticle adjustments get you zeroed in quicker and maintain your setting—even with repeated recoil.
Waterproof/Fogproof: Nitrogen filled and O-ring sealed.
Fully Multicoated Optical System: Provides up to 98% light transmission and maximum brightness from dawn to dusk.
Generous, Consistent Eye Relief: Keeps your brow safe—even with the heaviest recoiling cartridges, lightweight rifles, and severe shooting angles.
Zero-Reset Turret Feature: To simplify field adjustments, Nikon has integrated this feature into all new riflescopes. Just sight-in as usual, then lift the spring-loaded adjustment knob, rotate to your “zero”, and reengage. Field adjustments are now as simple as dialing-in your subsequent ranges.
Magnification 3 x
Objective Diameter 32 mm
Exit Pupil 10.7 mm
Field of View 35.6 ft @ 100 yds
Tube Diameter – Other 1 in
Eye Relief 3.4 in
Objective Outside Diameter 39.3 mm
Eyepiece Outside Diameter 41 mm
Weight 12.2 oz
Overall Length 8.1 in
Adjustment Graduation – Other 1/2 in
Max Internal Adjustment 100 MOA
Parallax Setting – Other 100 yds
Matte Finish Yes
Use Centerfire Short/Mid Range
AR (Modern Sporting Rifle)
Reticle BDC Carbine
